•    Solid-state reversing—no contactors

•    True series-wound motor configuration

•    LCD Operator Display

•    Fewer control components

•    One Box Solution – no modules

•    Protected motors

Improve Production

   *  Run cooler—run longer

   *  Cooler running motor controller

   *  Automatic motor protection

   *  Improved motor life

   *  Reduced Maintenance

   *  Reduced Mechanical Stress

   *  Reduced Power Consumption

   *  Up to 7:1 Current Multiplication

Microprocessor-Driven Performance

Cableform's proprietary microprocessor control of IGBTs (Isolated-Gate Bi-polar Transistors) provides LMC™- powered mining equipment with these performance advantages:

*  Maximum motor torque at all speeds

*  Smooth controlled acceleration

*  Smooth controlled braking

*  Adjustable parameter setting

*  Cooler running motors

*  Solid-State diagnostics

*  Motor protection Software

*  Solid-state reversing of the series-wound motor

   allows the inductive field winding, which is in series

   with the armature, to protect the armature against

   DI/DT current surges—it’s simple, it’s automatic.

*  One Microprocessor unit controls both Motors – no

   communication problems.

*  One current path per motor, resulting in significantly

   less thermal losses.

*  Suitable for both 30HP & 50HP motors

Size & Ratings

*  Nominal Output Voltage:    250 volts DC.

*  Peak Motor Current:           450 amps each.

*  Average Motor Current        400 amps each.

*  Electronic Overload:           Hardware and Software Protection

*  Weight:                            32Kg.

*  Size:                                630mm long by 387mm

                                          deep by 242mm high.
